INVT SL320 Loom Electronic Coiler Double Let-off Drives
INVT SL320 loom ETU and ELO system, which is the first “two-in-one” system in China, adopts two dedicated servo systems to replace the mechanical ETU and ELO of traditional loom. ETU and ELO module realize real-time data exchange via internal bus to achieve highly efficient linkage action. Real-time tension control, multiple kinds of compensation function and variable weft density weaving can be realized to eliminate various faults. It carries simple loom electronic controller interfaces and can be widely applied in water jet loom, air jet loom and rapier loom.
- The first “two-in-one” product in the industry. The electronic take-up and let-off module realizes real-time data exchange via internal bus to achieve highly efficient linkage action;
- Humanized HMI, fast and convenient parameter setup, real-time parameter monitoring;
- Beating-up density can be set via HMI without the need for changing the gear, and weft density-variable weaving can be performed at the same time;
- Real-time tension control, beam radius changes automatically to adapt to parameter modification, thus making tension control more stable and precise. Support fast protection against abnormal tension;
- Electronic take-up and let-off system carries stop compensation, startup compensation and cloth-fell compensation function. It can coordinate automatically to overcome the technical difficulties of stop gear;
- Able to stop the loom automatically and display fault type to ensure safe application and fast diagnosis when system fault occurred;
- Equipped with interfaces for dual-nozzle and triple-nozzle to realize convenient linkage action with the weft accumulator, thus ensuring a more precise weft density weaving.
